GLOW LED PANELS offer highly efficient optical system ensuring an effective low glare high efficiency lighting solution for residential, commercial and retail spaces. Panels are available in Round & Square configuration.
- Best suited for
-
Consumer Lighting
-
LED based Lighting Solution
Long lasting LED lighting solution with energy saving > 50%* -
Pressure die cast aIuminum housing
Epoxy White Powder coated Light weight corrosion resistant diecast aluminum housing luminaire with mid power LED -
High Efficiency Diffuser
High quality PMMA diffuser with highly reflective Light Guiding Plate for glare free & uniform light distribution -
Long Life
Long Life of 50,000 Hrs at L70 with easy installation & low maintenance -
Mounting
Suitable for Recessed Mounting with Modular and grid ceilings with 2 nos. spring -
Available CCTs
WW : 3000K
NW : 4000K
WH : 5700K
CW : 6500K -
IB LED Assurance
Surge Protection >2.5KV
THD < 10% -
Applications
Residential Segment
Commercial Segment
Retail Segment
Educational Segment
| Cat. Ref. | Rated System Wattage (W) | Rated Input Voltage (VAC) | Input Current (A) | CRI | Power Factor | Packing Case Lot (Nos.) |
| IRDLR21RD- 6-XX | 6±10% | 240 | 0.0278 | >80 | >0.9 | 10 |
| IRDLR21RD- 9-XX | 9±10% | 240 | 0.0417 | >80 | >0.9 | 10 |
| IRDLR21RD – 12-XX | 12±10% | 240 | 0.0556 | >80 | >0.9 | 10 |
| IRDLR21RD – 15-XX | 15±10% | 240 | 0.0694 | >80 | >0.9 | 10 |
| IRDLR21RD – 18-XX | 18±10% | 240 | 0.0833 | >80 | >0.9 | 10 |
